ENTRANCE MAT PLANNING INFORMATION

IMPORTANT NOTES AND INFORMATION BEFORE INSTALLATION

Made to measure entrance matting

CORRECT PLANNING FOR MATTING AND FRAMES

Please consider the following when planning the installation of a GEGGUS entrance matting system.


Geggus Installation Frame SPEZIAL

EXTERNAL CONTENT

Youtube

By accessing the external content, data is transmitted to the service provider.
By clicking on LOAD CONTENT you agree to the transmission to, and the privacy policy of, the provider.

Data protection information from the provider

Customer Service

Everything from one source – we offer a flexible and mobile service for digitally measuring and installing entrance matting systems (available on request at extra charge).

Customer Service

Fitting

Unless surface mounted, it is recomended that our entrance mats should always be in a matwell frame that is fitted flush with the floor.

When ordering, please remember:

For all 'Top Clean' mats for entrance areas, always indicate the profile length and the direction in which people will walk over the mat.

External frame size

When ordering a system frame with mat or drainage tray with mat, please state the external frame size. We deduct approx. 10 mm from this for the exact mat size.

Existing angle frames

If you already have an angle frame, please indicate the clear inside dimensions of the frame. We will deduct approx. 5 mm from this to calculate the production size for your mat.

Multi-part mats

For large entrance areas, mats with a profile length of more than 300 cm and/or a weight of more than 50 kg should be divided, as they will otherwise be too bulky or too heavy for installation and maintenance.

Drainage

When installing angle frames or wells in outdoor areas, drainage should be provided so that water can drain away (e.g. by making an opening in the screed), or the mat well should be connected to the GEGGUS 'Dirt Collection Tray' drainage system.

Laying mats without a frame

For surface mounted systems, our Top Clean TREND® mat in 10 and 17-mm versions can be equipped with a ramped edge so that a well is not required for any subsequent relaying.

Mats for heavily frequented areas

For entrance areas with heavy traffic (for example, in airports, supermarkets, shopping centres etc.) we recommend our aluminium profile mats Top Clean STABIL, Top Clean OBJEKT and Top Clean HIGH, all of which meet the special footfall, weight-bearing and durability requirements of these locations

Special designs

For special designs we recommend a weather-resistant and durable PVC template.

Attention!

If you are providing a template, please always roll it and never fold it. The upper side of the template and the walking direction must be clearly marked on it. Only with these exact specifications can a dimensionally accurate entrance mat be made.
